Cooling Performance

• (a) Total Cooling Capacity (KW): 0.75
• Sensible Cooling Capacity (KW): 0.61
• Water Flow Rate (L/h): 142
• Water Pressure Drops (kPa): 7.00

Dimensions and Weight

• Net Dimensions (LxWxH) (mm): 694 x 134 x 588
• Package Dimensions (LxWxH) (mm): 720 x 165 x 630
• Net Weight (Kg): 14
• Gross Weight (Kg): 15

Heating Performance

• (b) Heating Capacity (KW): 0.99
• Water Flow Rate (L/h): 142
• Water Pressure Drops (kPa): 6.50
• (c) Heating Capacity (KW): 1.55
• Water Flow Rate (L/h): 162
• Water Pressure Drops (kPa): 7.00

Components

• Coil Water Content (L): 0.48
• Maximum Operating Pressure (bar): 10
• Water Pipe Connector (inches): G1/2
• (d) Maximum Air Flow (m³/h): 160
• (d) Minimum Air Flow (m³/h): 50

Power Supply

• Power Supply (V/ph/Hz): 230/1/50
• Maximum Running Current (A): 0.1
• Maximum Power Input (W): 23
• (e) Maximum Noise Level (dB(A)): 39
• (e) Minimum Noise Level (dB(A)): 19.8

Note:

1. Cooling: Water inlet/outlet 7/12°C, room temperature DB/WB 27/19°C
2. Heating: Water inlet 50°C, water flow rate as in cooling operation, room temperature 20°C
3. Heating: Water inlet 70°C, outlet 60°C, room temperature 20°C
4. Air flow measured with clean filter
5. Noise tested as per ISO23741/2 and ISO7779:2001

The specifications are subject to change without prior notice. For actual specifications of unit, please refer to the stickers on the unit.
