LXP3600 Hybrid

""

A powerful single unit solution, the LXP3600 Hybrid is the solution for both solar inversion and battery storage.

These Lux Hybrid units are available in single-phase solutions and are available in five different sizes – 3.6 (16A limited), 5kW, 6kW, 7kW and 12kW. Components required for installation and monitoring connection are provided with each unit as standard.

The 3600 Hybrid can have up to 7kW of PV panels attached although it is 16A limited. It can therefore supply up to 3.6 kw of power from the solar to the load, and at the same time charge up to 3.4kw of power into the batteries.
Fully monitorable on the LuxPower App or web portal which allows users background performance insights and technical support.



""

Lxp3600 at a glance

Key LXP3600 Features

works-with-octopus

12-year warranty as standard – which can be extended to a 20-year warranty

Allows one to eight lithium batteries

Firmware and parameter remote upgrades

Free mobile & web portal monitoring

Advanced weather compensation programming

Seamless automatic switch over – 0.01s

Integrated EPS as standard – maximum 13A limited

Smart export control on both AC & EPS output

Max charge & discharge rates of 80A

Lightweight – only 25kg

Quiet operating levels – less than 25dB

IP65 rated

UK technical Support

Grid Share Incentive ready

Octopus Agile, Outgoing & Go Tariff Ready

12-year warranty as standard – which can be extended to a 20-year warranty

Allows one to eight lithium batteries

Firmware and parameter remote upgrades

Free mobile & web portal monitoring

Advanced weather compensation programming

Seamless automatic switch over – 0.01s

Integrated EPS as standard – maximum 13A limited

Smart export control on both AC & EPS output

Max charge & discharge rates of 80A

Lightweight – only 25kg

Quiet operating levels – less than 25dB

IP65 rated

UK technical Support

Grid Share Incentive ready

Octopus Agile, Outgoing & Go Tariff Ready

Product Outline

LXP3600 Full Specifications

Maximum DC Input Power: 7000W

Nominal DC Input Voltage: 360V.d.c

DC Input Voltage Range: – 100 – 550V.d.c (Configurable)

MPPT Voltage Range: – 120 – 500V.d.c

Start-up Voltage: – 140V.d.c

MPPT Number: – 2

Max. DC Input Current: – 12.5A/12.5A

Max. Short-circuit Currant: – 13.7A/13.7AMax. Input Power Per MTTP: – 3500W/3500W

Max. Feedback Current to Array: – 0/0A

Compatible Battery Type: Lithium-ion/lead-acid

Nominal Battery Voltage: 48V.d.c

Battery Voltage Range: 40 – 60V.d.c

Maximum Charge/Discharge Current: 80A/80A

Maximum Charge/Discharge Power: 3600W/3600W

Charging Curve: 3-stages

Maximum Charge Voltage: 59V

DOD (lithium-ion/Lead Acid): 80%/50%

Capacity of Battery: 2-20kWh

Nominal AC Output Power: 3600W

Maximum AC Output Power: 3600VA

Maximum AC Output Current: 16A

Nominal AC Voltage: 230V

Optional AC Voltage Range: 180-270Vac

Nominal AC Frequency: 50Hz/60Hz

AC Frequency Range: 45-55Hz/55-65Hz

Power Factor: Adjustable 0.8 overexcited to 0.8 underexcited

THDI: <3%

Inrush Current: 10A/10us

Maximum Output Fault Current: 50A/20us

Maximum Output Over Current Protect: 20A

Solar Input

Maximum DC Input Power: 7000W

Nominal DC Input Voltage: 360V.d.c

DC Input Voltage Range: – 100 – 550V.d.c (Configurable)

MPPT Voltage Range: – 120 – 500V.d.c

Start-up Voltage: – 140V.d.c

MPPT Number: – 2

Max. DC Input Current: – 12.5A/12.5A

Max. Short-circuit Currant: – 13.7A/13.7AMax. Input Power Per MTTP: – 3500W/3500W

Max. Feedback Current to Array: – 0/0A

Battery Input / Output

Compatible Battery Type: Lithium-ion/lead-acid

Nominal Battery Voltage: 48V.d.c

Battery Voltage Range: 40 – 60V.d.c

Maximum Charge/Discharge Current: 80A/80A

Maximum Charge/Discharge Power: 3600W/3600W

Charging Curve: 3-stages

Maximum Charge Voltage: 59V

DOD (lithium-ion/Lead Acid): 80%/50%

Capacity of Battery: 2-20kWh

AC Input/Output

Nominal AC Output Power: 3600W

Maximum AC Output Power: 3600VA

Maximum AC Output Current: 16A

Nominal AC Voltage: 230V

Optional AC Voltage Range: 180-270Vac

Nominal AC Frequency: 50Hz/60Hz

AC Frequency Range: 45-55Hz/55-65Hz

Power Factor: Adjustable 0.8 overexcited to 0.8 underexcited

THDI: <3%

Inrush Current: 10A/10us

Maximum Output Fault Current: 50A/20us

Maximum Output Over Current Protect: 20A

400

Units sold in the UK

Lxp3600 in depth

LXP3600 Product Overview

Up To 20 Years Warranty

All our LuxPower Controllers come with a comprehensive 12-year manufacturer’s warranty, ensuring that you can rely on the performance and longevity of our products with absolute confidence. At an extra charge, this can be upgraded to 20 years warranty, giving you peace of mind when it comes to your investment.

66Amps Charge & Discharge Rates

The charge rate determines how much power your batteries store, how much solar you can harvest and how fast your batteries charge. The discharge rate determines how much load you can cover when there is no more solar and you are covering your load from the batteries. Luxpower 3.6 Hybrids have up to a 72A charge and discharge.

Using low-voltage batteries connected in parallel, the system is always using a 50V system, and this combined with the 72A charge rate results in 3600W of power.

Advanced Monitoring

Our Lux Power range comes with Free Advanced Monitoring that gives you a full insight to your system showing more information than you can handle. The platform is an overview of the system performance providing daily, weekly and monthly information.

This platform allows you to simply change settings such as charge rates and make use of the excellent FREE lux programs. The Luxpower monitoring can be viewed via a web portal on laptops and PCs or Mobile App for smartphones and tablets.

Advanced Weather Compensation Programming

The LuxPower range now comes with advanced weather compensation, which makes weather predictions. This feature allows users to program night-time grid charging of the controller and batteries based on the following days local weather forecast.

The feature will allow users to operate the battery at its optimum level and increase efficiencies, and as a result save more money.

Advanced EPS

The Lux Power LXP 3600 AC Controller has an impressive, enhanced EPS feature will switch over in 0.01s in the event of a power cut, meaning these systems can also be used with Grid Share incentive programmes.

Grid Charge & Octopus Agile/Outgoing/Go Compatible

New energy providers will now provide extremely cheap off-peak renewable electricity. The LuxPower LXP 3600 Hybrid can be programmed to take advantage of these cheap off-peak tariffs to charge the batteries to use the energy when the tariffs are high.
