Thermopod Heat Pump
Producing piping hot water in the coldest of conditions, the Thermopod unit absorbs heat energy from a range of sources.
Harnessing heat from solar, air and ground as well as via two external panels, all natural elements such as air temperature, wind, rain, sunlight and even snow can be a heat source. This is because the ThermoPOD unit extracts heat from refrigerant that returns from the panels before it is transferred into the water within its hot water cylinder. With a default setting of keeping water at 55°C, the ThermoPOD can detect drops in temperature to return it to its original state. This means that you will always have hot water when you need it.
Features at a Glance
Key Product Features
All year-round performance
Connectible with any invented hot water cylinder
Less than 0.5kW per hour
Ideal in domestic or commercial applications
Quick installation
Day and night hot water
100% of hot water system needs
Low operating noise
Low cost – highly efficient
Simple and flexible structure
ThermoPOD Outline
ThermoPOD Specifications
Cover: Cold rolled steel
Chassis Base: Galvanized steel
Dual Panel Thermal Power (Maximum): 2690W
Consumption (Rated): 400W
Sound Level: ≤41dB(A)
Power Supply: 230-50 V/Hz
Operating Current (Maximum): 13 amps
Pre-set Water Temperature: 53°C
Maximum Water Temperature: 60°C
Max Operating Water Pressure: 8 Bar
Operating Temperature Range: -8～+40℃
Refrigerant Connection (Inlet/Outlet): 3/8- 1/4″
Refrigerant Charge (134A): 1400g
Disinfection Cycle (Auto): Weekly
Protection: IP21
Dimensions: 500x395x270mm
Welight (Pre-Charged): 39 Kg
Warranty: 10 years
Material: Aluminium (Powder Coated)
Material Thickness: 2mm
Height: 2000mm
Width: 800mm
Frame Depth: 25mm
PreDiled Fixing Points: 6
Weight: 8.9kg
Panel Design: Patent pending
Warranty: 10 years
ThermoPOD in depth
ThermoPOD Overview
Multiple Thermal Sources
Absorbing energy from multiple sources like solar, air, wind and rain, the ThermoPOD works 24 hours a day.
Exceptional Efficiency
As it is a low-carbon competitive product, it operates at an average of 20% lower than a heat pump hot water system.
Low Noise
The ThermoPOD doesn’t require a motor fan, which means that there is low operating noise.
