Harnitek Air Source
Heat Pump
The Harnitek R32 heat pump is built for exceptional efficiency and reliability.
Capable of flow temperatures up to 60°, making it the ideal choice for new and existing heating systems. Incredibly quiet operation when in use, the lightweight R32 delivers exceptional cold and warm weather performance efficiently.
Flexible installation options, and the hybrid compatibility allows it to play a part in a wider system.
Harnitek Air Source at a Glance
Key Harnitek Air Source Features
Hybrid system ready
Flexible installation options
Easy installation
Smart monitoring and remote control
Quiet functionality
Touch screen LED display
Exceptional Efficiency ERP Rated A+++
Seasonal COP (SCOP) 4.7
UK training and technical support
Advanced Online Monitoring
Harnitek Air Source Outline
Harnitek Air Source Specifications
Power Supply: 220-240V / 50Hz / 1-R32Ph
Max Heating Capacity: 6.5kW
C.O.P: 4.61
Heating Capacity Minimum/Maximum: 3.5 – 6.5kW
Heating Power Input Minimum/Maximum: 758 – 1410W
C.O.P Minimum/Maximum: 4.5 – 4.7
Compressor: Twin Rotary – 1
Fan Airflow: 2500m3/h
Fan Rated Power: 34W
Noise Level (Indoor – Outdoor): 38 – 52 dB
Water Side: Plate Heat Exchanger
Heat Exchanger Water Pressure Drop: 26kPa
Heat Exchanger Piping Connection: G1”
Allowable Water Flow (Minimum – Rated – Maximum): 0.21 – 0.29 – 0.35
Net Dimension Indoor Unit (Length x Depth x Height): 570 x 550 x 225
Net Dimension Outdoor Unit (Length x Depth x Height): 1010 x 370 x 700
Net Weight Indoor Unit: 25kg
Net Weight Outdoor Unit: 65kg
Power Supply: 220-240V / 50Hz / 1-R32Ph
Max Heating Capacity: 9.2kW
C.O.P: 4.38
Heating Capacity Minimum/Maximum: 4.3 – 9.2kW
Heating Power Input Minimum/Maximum: 927 – 2097W
C.O.P Minimum/Maximum: 4.38 – 4.71
Compressor: Twin Rotary – 1
Fan Airflow: 3150m3/h
Fan Rated Power: 45W
Noise Level (Indoor – Outdoor): 38 – 53 dB
Water Side: Plate Heat Exchanger
Heat Exchanger Water Pressure Drop: 26kPa
Heat Exchanger Piping Connection: G1”
Allowable Water Flow (Minimum – Rated – Maximum): 0.26 – 0.43 – 0.52
Net Dimension Indoor Unit (Length x Depth x Height): 570 x 550 x 255
Net Dimension Outdoor Unit (Length x Depth x Height): 1165 x 370 x 845
Net Weight Indoor Unit: 25kg
Net Weight Outdoor Unit: 78kg
Power Supply: 220-240V / 50Hz / 1-R32Ph
Max Heating Capacity: 11.6kW
C.O.P: 4.3
Heating Capacity Minimum/Maximum: 5.5 – 11.6kW
Heating Power Input Minimum/Maximum: 1107 – 2683W
C.O.P Minimum/Maximum: 4.3 – 4.9
Compressor: Twin Rotary – 1
Fan Airflow: 3150m3/h
Fan Rated Power: 45W
Noise Level (Indoor – Outdoor): 38 – 52 dB
Water Side: Plate Heat Exchanger
Heat Exchanger Water Pressure Drop: 26kPa
Heat Exchanger Piping Connection: G1”
Allowable Water Flow (Minimum – Rated – Maximum): 0.34 – 0.57 – 0.68
Net Dimension Indoor Unit (Length x Depth x Height): 570 x 550 x 225
Net Dimension Outdoor Unit (Length x Depth x Height): 1165 x 370 x 845
Net Weight Indoor Unit: 25kg
Net Weight Outdoor Unit: 85kg 85kg
Harnitek Air Source in depth
Harnitek Air Source Overview
Next Generation Efficiency
The entire range of Air Source Heat Pumps are ERP rated A+++. This means that they perform efficiently at low and medium outputs. They also have a market-leading SCOP of 4.7, which means that fast recovery times and peak performance is available no matter what time of the year it is.
Performance Hub Gateway
All Harnitek Smart Hub units, including the Air Source Heat Pumps can be linked to the internet through the integrated Wi-Fi module. The online Performance Hub Gateway gives installers a fully programmable platform for programming the system and optimising the efficiency and performance including real time diagnosis and failure / fault alert.
LED Touchscreen
A large and clear LED controller is simple to use, making programming easy to understand and master. From basic quick functions to extended system analysis, the screen provides a wide range of control.
Lightweight Units
The lightweight outdoor units make handling and installing them manageable for two engineers. As well as this, they are suitable for wall mounting without the need for heavy lifting equipment.
Quiet Functionality
Rated at only 38db at 2.1m, the Air Source Heat Pumps perform at their peak level whilst making little sound. Settings allow additional quiet mode for the most sensitive locations.
UK Technical Support and Training
All Harnitek heat pumps are supported by a UK-based training and support centre. Usually installed successfully, should any further issues arise, support can be carried out remotely through the Performance Hub Gateway.
Hybrid Compatible
The heat pumps are compatible with any secondary heating source. Once connected to the Smart Hub, this can then allow secondary sources to contribute to your overall heating demand.
Simple Installation
Harnitek heat pumps are designed to have a simple and straight forward installation process.
Many of the technical aspects of heat pump installation are pre-assembled into the Smart Hub, saving installers time and allowing all key components to be monitored via the Performance Hub Gateway.
